Replacement Hydac Hydraulic Filter Element

  • Wind power filter element for Hydac 1300R010BN4HC/-B4-KE50
  • Wind power filter element for Hydac 1300R010BN4HC/-B4-KE50
  • Wind power filter element for Hydac 1300R010BN4HC/-B4-KE50
Wind power filter element for Hydac 1300R010BN4HC/-B4-KE50Wind power filter element for Hydac 1300R010BN4HC/-B4-KE50Wind power filter element for Hydac 1300R010BN4HC/-B4-KE50

Wind power filter element for Hydac 1300R010BN4HC/-B4-KE50

  • Filtration accuracy: 10um
  • Filter material: Nanjing fiberglass, Rand fiberglass imported from the United States, 304 stainless steel metal mesh
  • Working pressure: 16bar
  • Working temperature: -30℃~+110℃
  • Description: Wind power filter element 1300R010BN4HC/-B4-KE50 Product introduction: Used for wind power hydraulic station filter element in hydraulic system, used to filter solid particles and colloidal substan
  • INQUIRY   EMAIL

Whatsapp Me

●Wind power filter element 1300R010BN4HC/-B4-KE50 Product introduction:


Used for wind power hydraulic station filter element in hydraulic system, used to filter solid particles and colloidal substances in the working medium, and effectively control the pollution degree of the working medium. The system can quickly reach and maintain the desired level of oil cleanliness, and can extend the life of the oil.
Mainly used for the filtration of the hydraulic system of the wind power station turbine. The difference between this filter element and the ordinary filter element is that the filter element contains a stainless steel mesh filter element with a lower precision to ensure that the filter element is blocked during use and when the bypass valve is opened The filter element can still achieve a certain filtering effect, reducing unnecessary equipment wear and extending the service life of the equipment.


●Technical parameters

Filtration accuracy: 10um
Filter material: Nanjing fiberglass, Rand fiberglass imported from the United States, 304 stainless steel metal mesh
Working pressure: 16bar
Working medium: general hydraulic oil, phosphate grease hydraulic oil, emulsion, water-glycol

Working temperature: -30℃~+110℃


●Performance characteristics

Axial stiffness: The filter element should not be deformed or damaged when it bears the axial load of the industry process document standard.
Flattening stiffness: When the filter element is subjected to the ultimate pressure drop in the industry process document standard, it should not be deformed or damaged.
Pressure drop flow characteristics: The pressure drop flow characteristics curve of the standard filter element should be specified in the industry process document.
Flow fatigue characteristics: under standard flow and pressure drop conditions.

●Working principle
The strong hydrophobic and oleophobic fiber filter material is used, and the framework with good permeability and high strength is used to reduce the resistance caused by passing.
The use of a fine-opening sponge can effectively prevent the oil and water from being entrained by the high-speed airflow, so that the small oil droplets that pass down the road gather at the lower end of the filter sponge and discharge to the bottom of the filter container.
The connection point of the filter element and the filter housing adopts a reliable sealing ring to ensure that the air flow is not short-circuited and prevent impurities from directly entering the downstream without passing through the filter element.
The filter element adopts anti-corrosion reinforced nylon end cap and anti-corrosion filter element frame, which can be used in harsh working conditions.

●Recommended model
1300R003BH3HC
1300R005BN/HC
1300R010P
1300R025W
