Technical parameters of UE610AT40Z Pall oil filter element:

1. Filter material: American Rand glass fiber / domestic CSG glass fiber filter paper

2. Precision: 5um

3. Size: UE610AT40Z

4. Filter: Multi-layer galvanized diamond mesh

5. Skeleton: carbon steel galvanized perforated sheet

6. Filtering medium: phosphate ester fire-resistant fuel or hydraulic oil before and after No. 46

7. Working pressure: 32MPA


Precautions for the use of UE610AT40Z Pall oil filter element:

1. The filter element is a consumable. Although it is more durable than other filter elements, it should be careful not to scratch, bump, drop, etc. during the cleaning and disassembly process to prevent human damage. It is strictly forbidden to use tools to exert force on the surface of the filter element.

2. Generally, the filtrate is filtered from the outside to the inside of the filter element, and reverse filtration is not recommended.

3. When filtering, pressurize slowly to the required working pressure, and it is strictly forbidden to open the full valve and pressurize quickly


It is mainly aimed at oil pollution in hydraulic system equipment, pollution caused by assembling accessories, and new oil entering pollution. The double filter HC8900FKT39H filter element is made of stainless steel metal mesh material, axially sealed connection, used for oil absorption and return The oil filter is installed in the oil tank and must be installed below the liquid level of the oil tank. The filter element should be judged according to the filter material, whether it can be cleaned and used repeatedly.
